Outdoor Self-Service Kiosk with Sunlight-Readable Display for Public Spaces
The Outdoor Self-Service Kiosk is built to withstand harsh environmental conditions, making it perfect for public spaces like parks, transit stations, and outdoor markets. Its sunlight-readable display ensures clear visibility even in direct sunlight.
The kiosk is equipped with a rugged, weatherproof enclosure and anti-vandal features to ensure long-lasting performance. With advanced connectivity options and customizable software, it provides a reliable self-service solution for ticketing, information, and ordering.
sunlight-readable touchscreen display；Weatherproof and anti-vandal enclosure；Rugged design for outdoor use；Advanced connectivity options (Wi-Fi, 4G, Ethernet)；Customizable software for ticketing and information services；High-brightness display for outdoor visibility；Energy-efficient operation
Suitable for public spaces, transit stations, outdoor markets, and tourist attractions.
| LCD Panel Parameters | Screen Size | 15.6 inch |
| Display area | 344.16(H) X 193.59(V)mm |
| Aspect Ratio | 16 : 9 |
| LCD Type | a-Si TFT-LCD |
| Max Resolution | 1920 X 1080 |
| Display color | 16.7M , 72% NTSC |
| Brightness | 350 cd/㎡ |
| Contrast Ratio | 3000 :1 |
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) |
| Response Time | 20ms |
| LCD Panel Life(hrs) | 60,000(hrs) |
| Field Frequency | 60Hz |
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen |
| Touch points | 10 points |
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof |
| Anti-microbial protection and Shatterproof Protection |
| Optically bonded 3mm glass for low parallax |
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% |
| Response speed | < 6ms |
| Accuracy of touch | More than 90% of the touch area ±2mm |
| Touch ways | Fingers, touch pen |
| Output format | The coordinate output |
| Clicks time | Unlimited |
| The smallest touch size | 5mm |
| Long resistance | Yes available |
| Touch Interfaces | USB |
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH |
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH |
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 |
| RAM | 8GB |
| SSD | 64GB |
| WIFI | 150Mbps 802.11n wifi integate |
| Network port | RJ45, 10M/100M Adaptive Ethernet |
| Interface | 2 * RJ45 GB Ethernet |
| 2 * RS232 Serial Port |
| operating system | Win10 or win11 optional |
| Onboard interface | HDMI input | 1 |
| VGA input | 1 |
| DVI input | 1 |
| USB Type B or Any USB Type optional | 1 |
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode |
| Receipt Printer | 80mm Thermal printer with cutter |
| Power | Power supply | AC 100V~240V, 50/60Hz |
| The Max power loss | ≤ 45w |
| Standby power loss | < 1W |
| Features | Operating temperature | 0℃ ~ 50℃ |
| Storage temperature | below10℃ ~ +60℃ |
| Accessories | The length of Power Cable | 1.5m |
| The length of HDMI Cable | 2m |
| The length of USB-A to USB-B Cable | 1.5m |
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable |
| Package size | Machine body size | Customized |
| Net weight | Customized |
| Unit Package size | 450 X 310 X 110mm |
| The Gross weight of Unit Package | 50kg |
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
